Cần siết chỉnh lực 8-40Nm Stahlwille 730/4

Cần xiết chỉnh lực 8-40 Nm Stahlwille 730/4.

Mã hàng: 50180004

- Lực siết 8-40 Nm

- Lỗ lắp đầu cần siết: 9x12mm

- Chiều dài tổng: 222mm

- Lưu ý: dòng cần siết này chưa bao gồm đầu cần siết phải chọn mua thêm

Code	Size				b	h	L	LF	SF
				mm	mm	mm	mm	mm	mm	g
50180002	2	4-20 N·m	0,5 N·m		27,5	23	178,5	174	17,5	315
50180004	4	8-40 N·m	1 N·m		27,5	23	222	218	17,5	395
50580001	a/2-1	17,5-87,5 in·lb	2,5 in·lb		27,5	23	178,5	174	17,5	315
50580002	a/2	30-175 in·lb	5 in·lb		27,5	23	178,5	174	17,5	315
50580004	a/4	70-350 in·lb	10 in·lb		27,5	23	222	218	17,5	395

730 - Basic wrenches with tool carrier for insert tools

Service MANOSKOP® 730

- Cut-out type
- Mount for interchangeable insert/shell tools
- QuickRelease safety lock (sizes 5-65)
- Rapid setting (sizes 2-65)
- Dual stop signal
- Twin scales N·m/ft·lb and N·m/in·lb (sizes 5-80)
- The measuring element is only under load while force is being applied, no need for manual reset to zero
- Can be applied for either clockwise or anticlockwise tightening by turning the inserts over
- Any force applied to the tool after the 'click' or applied in the opposite direction to the current function - e.g.
forcible loosening of a jammed screw - does not act on the trigger mechanism and cannot cause damage to it.
- Calibration using perfectControl calibrating unit No 7794 or calibration system No 7706. Adjustment without disassembly.
- With certificate
- Display deviation value ± 4%
