Cảo thủy lực 2 chấu 15 tấn Omarstar CK-104HA

Cảo thủy lực 2 chấu 15 tấn Omarstar CK-104HA

Wide Spread Puller CK-104HA

- Self-contained Hydraulic Puller, no need for extra hand pump, hose and coupling, allows operating by one person.

- 360° Rotary handle swivel clevis allows pumping at all directions.

- Safety valve minimizes the risk of the puller overload by limiting the applied force

- Complete hydraulic puller allows effortless generation of force and dismounting.

- The spring-loaded centre point of the hydraulic spindle allows easy centering the puller on the shaft.

- Forging parts and special treatment provide long life service and the best strength.

- This kind of product is widely used in steel mills, wire roll/extruding companies, textile industry, and any straightening situation that portability and power are required.

Output	Item No.	Spread	Stroke	Jaw Tip (mm)			Net Weight	Gross Weight
Ton Max.	Item No.						N.W	G.W
		(mm)	(mm)	A	B	C
15 Tons	CK-104H	100/410	82-180	ØM60			14.48	22.9
15 Tons	CK-104HA	100/410	82-180	32	8	26	13.3	21.65
15 Tons	CK-104HB	100/410	82-180	ØM60/32	8	26	16.85	25.2
