Cảo thủy lực 3 chấu 10 tấn TLP HHL-10

Liên hệ

Mã sản phẩm: HHL-10
Thương hiệu: TLP
Công nghệ: Nhật
Xuất xứ: Trung Quốc
Bảo hành: 06 Tháng
Trọng lượng: 11.0 kg

Title:

Kích thước:

Màu sắc:

Hydraulic Gear Puller 2-jaw and 3-jaw
- The integral pullers are compact, lightweight. Easy to carry and operate. It's least restricted by place and is extensively used by factories, repair stations and etc.
- Both 2-jaw and 3-jaw styles are available
- The handle's removeable and can be pressed at 360° direction which benifit using in limit space
- High quality return piston ,quick return the Piston rod was hard chrome plating , high safety factor and with long lifetime
- The Cylinder body out of the Piston was blacken treated
- Claw and the frame were forged with high strength alloy steel , not easy to deformation and chrome plated

Model	HHL-5	HHL-10	HHL-20	HHL-30	HHL-50
Rated output(T)	5	10	20	30	50
Max. spread(mm)	200	250	350	400	500
Max. stroke(mm)	50	50	60	60	60
Weight(kg)	7.5	11	19	25	45
Volume(cm)	(1/4)443832	(1/2)442136	434014	482018	522522

Mô tả

Cảo thủy lực 3 chấu 10 tấn TLP HHL-10, Bộ cảo thủy lực 3 chấu 10 tấn TLP HHL-10.

Model	HHL-5	HHL-10	HHL-20	HHL-30	HHL-50
Rated output(T)	5	10	20	30	50
Max. spread(mm)	200	250	350	400	500
Max. stroke(mm)	50	50	60	60	60
Weight(kg)	7.5	11	19	25	45
Volume(cm)	(1/4)443832	(1/2)442136	434014	482018	522522
