Cảo thủy lực 3 chấu 30 tấn Omarstar CK-15IN

Liên hệ

Mã sản phẩm: CK-15IN
Thương hiệu: Omarstar
Công nghệ: Nhật
Xuất xứ: Đài Loan
Bảo hành: 06 Tháng
Trọng lượng: 64.35 kg

Title:

Kích thước:

Màu sắc:

Cảo thủy lực 3 chấu 30 tấn Omarstar CK-15IN

Cobra 10~30 Ton

- Self-contained Hydraulic Puller, no need for extra hand pump, hose and coupling, allows operating by one person.

- 2 / 3 jaws combination puller head.

- Life time warranty for cobra jaws.

- 360°Rotary handle swivel clevis allows pumping at all directions.

- Safety valve minimizes the risk of the puller overload by limiting the applied force.

- Complete hydraulic puller allows effortless generation of force and dismounting.

- The spring-loaded centre point of the hydraulic spindle allows easy centering the puller on the shaft.

- Forging parts and special treatment provide long life service and the best strength.

Output	Item No.	Reach	Spread	Stroke	Jaw Tip (mm)			Net Weight	Gross Weight
Ton Max.	Item No.							N.W	G.W



		(mm)	(mm)	(mm)	A	B	C
10 Tons	CK-6IN Extra	195	30-250/310	82-130	13	5	22	7.4	10.7
10 Tons	CK-6INL Extra	250	30-280/340	82-180	15	8	25	9.9	18.3
12 Tons	CK-8IN Extra	240	30-300-370	82-160	15	8	25	10.6	19
12 Tons	CK-8INL Extra	280	30-330/400	82-240	18	8	29	12.55	23.3
20 Tons	CK-11IN	275	50-360/430	82-180	18	8	29	14	24.65
20 Tons	CK-11INL	330	50-380/450	82-280	28	11	33	16.5	29.3
25 Tons	CK-12IN	315	50-410/480	110-220	28	11	33	21.95	34.8
25 Tons	CK-12INL	380	50-440/540	110-330	30	14	40	26.46	43.8
30 Tons	CK-15IN	405	100-540/610	110-260	30	14	40	35.4	52.65

Mô tả

Cảo thủy lực 3 chấu 30 tấn Omarstar CK-15IN

Cobra 10~30 Ton

- Self-contained Hydraulic Puller, no need for extra hand pump, hose and coupling, allows operating by one person.

- 2 / 3 jaws combination puller head.

- Life time warranty for cobra jaws.

- 360°Rotary handle swivel clevis allows pumping at all directions.

- Safety valve minimizes the risk of the puller overload by limiting the applied force.

- Complete hydraulic puller allows effortless generation of force and dismounting.

- The spring-loaded centre point of the hydraulic spindle allows easy centering the puller on the shaft.

- Forging parts and special treatment provide long life service and the best strength.

Output	Item No.	Reach	Spread	Stroke	Jaw Tip (mm)			Net Weight	Gross Weight
Ton Max.	Item No.							N.W	G.W



		(mm)	(mm)	(mm)	A	B	C
10 Tons	CK-6IN Extra	195	30-250/310	82-130	13	5	22	7.4	10.7
10 Tons	CK-6INL Extra	250	30-280/340	82-180	15	8	25	9.9	18.3
12 Tons	CK-8IN Extra	240	30-300-370	82-160	15	8	25	10.6	19
12 Tons	CK-8INL Extra	280	30-330/400	82-240	18	8	29	12.55	23.3
20 Tons	CK-11IN	275	50-360/430	82-180	18	8	29	14	24.65
20 Tons	CK-11INL	330	50-380/450	82-280	28	11	33	16.5	29.3
25 Tons	CK-12IN	315	50-410/480	110-220	28	11	33	21.95	34.8
25 Tons	CK-12INL	380	50-440/540	110-330	30	14	40	26.46	43.8
30 Tons	CK-15IN	405	100-540/610	110-260	30	14	40	35.4	52.65
