DANH MỤC SẢN PHẨM

Cảo thủy lực 6 tấn càng dài Omarstar CK-6INL

Liên hệ

Mã sản phẩm: CK-6INL
Thương hiệu: Omarstar
Công nghệ: Nhật
Xuất xứ: Đài Loan
Bảo hành: 06 Tháng
Trọng lượng: 8.8 kg

Title:

Kích thước:

Màu sắc:

Cảo thủy lực 6 tấn càng dài Omarstar CK-6INL

4~15 Tons Portable Puller

- Self-contained hydraulic puller, no need for extra hand pump, hose and coupling, allows operating by one person.

- Use with 2 or 3 jaws.

- 360° rotary handle swivel clevis allows pumping at all directions.

- Fast adjusting nut allows speedy adjusting reach.

- Safety valve minimizes the risk of the puller overload by limiting the applied force.

- Complete hydraulic puller allows effortless generation of force and dismounting.

- The spring-loaded centre point of the hydraulic spindle allows easy centering the puller on the shaft.

- Forging parts and special treatment provide long life service and the best strength.

Output	Item No.	Reach	Spread	Stroke	Jaw Tip (mm)			Net Weight	Gross Weight
Ton Max.	Item No.							N.W	G.W



		(mm)	(mm)	(mm)	A	B	C
4 Tons	CK-6SD	165	30-200/260	55-105	15	7	22	5.49	7.2
6 Tons	CK-6IN	165	30-200/260	82-130	15	7	22	5.85	7.5
6 Tons	CK-6INL	195	30-200/300	82-180	20	7	26	7.01	8.8
8 Tons	CK-8IN	210	30-250/355	82-160	20	7	26	8.05	9.7
8 Tons	CK-8INL	240	30-300/380	82-240	20	9	30	9.4	11.1
15 Tons	CK-10IN	240	50-280/380	82-180	20	9	30	9.75	11.1

Mô tả

Cảo thủy lực 6 tấn càng dài Omarstar CK-6INL

4~15 Tons Portable Puller

- Self-contained hydraulic puller, no need for extra hand pump, hose and coupling, allows operating by one person.

- Use with 2 or 3 jaws.

- 360° rotary handle swivel clevis allows pumping at all directions.

- Fast adjusting nut allows speedy adjusting reach.

- Safety valve minimizes the risk of the puller overload by limiting the applied force.

- Complete hydraulic puller allows effortless generation of force and dismounting.

- The spring-loaded centre point of the hydraulic spindle allows easy centering the puller on the shaft.

- Forging parts and special treatment provide long life service and the best strength.

Output	Item No.	Reach	Spread	Stroke	Jaw Tip (mm)			Net Weight	Gross Weight
Ton Max.	Item No.							N.W	G.W



		(mm)	(mm)	(mm)	A	B	C
4 Tons	CK-6SD	165	30-200/260	55-105	15	7	22	5.49	7.2
6 Tons	CK-6IN	165	30-200/260	82-130	15	7	22	5.85	7.5
6 Tons	CK-6INL	195	30-200/300	82-180	20	7	26	7.01	8.8
8 Tons	CK-8IN	210	30-250/355	82-160	20	7	26	8.05	9.7
8 Tons	CK-8INL	240	30-300/380	82-240	20	9	30	9.4	11.1
15 Tons	CK-10IN	240	50-280/380	82-180	20	9	30	9.75	11.1
