Dao phay hợp kim 2me cổ dài YG1 EMC59

Liên hệ

Mã sản phẩm: EMC59
Thương hiệu: YG1
Công nghệ: Hàn Quốc
Xuất xứ: Hàn Quốc
Bảo hành: 06 tháng
Trọng lượng: 0.1 Kg

Title:

Kích thước:

Màu sắc:

Dao phay ngón hợp kim 2me cổ dài K-2 Plus YG1 EMC59...series

Vật liệu: Carbide (hợp kim)

CARBIDE, 2 FLUTE LONG NECK EMC59 SERIES

- Designed for general purposes to carbon steels, tool steels, alloy steels and stainless steels.
- Deep slotting is possible by reduced neck.
- Suitable for high speed machining in wet or dry condition.

EDP No.	Mill	Shank	Length	Length	Overall	Neck
	Diameter	Diameter	of Cut	Below Shank	Length	Diameter
UNCOATED	D1	D2	L1	L3	L2	D3
EMC59004010	0.4	4	0.6	1	45	0.37
EMC59004020	0.4	4	0.6	2	45	0.37
EMC59004030	0.4	4	0.6	3	45	0.37
EMC59004040	0.4	4	0.6	4	45	0.37
EMC59004050	0.4	4	0.6	5	45	0.37
EMC59005020	0.5	4	0.7	2	45	0.45
EMC59005030	0.5	4	0.7	3	45	0.45
EMC59005040	0.5	4	0.7	4	45	0.45
EMC59005060	0.5	4	0.7	6	45	0.45
EMC59005080	0.5	4	0.7	8	45	0.45
EMC59006020	0,6	4	0.9	2	45	0.55
EMC59006030	0.6	4	0.9	3	45	0.55
EMC59006040	0.6	4	0.9	4	45	0.55
EMC59006060	0.6	4	0.9	6	45	0.55
EMC59006080	0.6	4	0.9	8	45	0.55
EMC59006100	0.6	4	0.9	10	45	0.55
EMC59007020	0.7	4	1	2	45	0.65
EMC59007040	0.7	4	1	4	45	0.65
EMC59007060	0.7	4	1	6	45	0.65
EMC59007080	0.7	4	1	8	45	0.65
EMC59007100	0.7	4	1	10	45	0.65
EMC59008020	0.8	4	1.2	2	45	0.75
EMC59008040	0.8	4	1.2	4	45	0.75
EMC59008060	0.8	4	1.2	6	45	0.75
EMC59008080	0.8	4	1.2	8	45	0.75
EMC59008100	0.8	4	1.2	10	45	0.75
EMC59008120	0.8	4	1.2	12	45	0.75
EMC59009060	0.9	4	1.4	6	45	0.85
EMC59009080	0.9	4	1.4	8	45	0.85
EMC59009100	0.9	4	1.4	10	45	0.85
EMC59009150	0.9	4	1.4	15	50	0.85
EMC59010040	1.0	4	1.5	4	45	0.95
EMC59010050	1.0	4	1.5	5	45	0.95
EMC59010060	1.0	4	1.5	6	45	0.95
EMC59010080	1.0	4	1.5	8	45	0.95
EMC59010100	1.0	4	1.5	10	45	0.95
EMC59010120	1.0	4	1.5	12	45	0.95
EMC59010140	1.0	4	1.5	14	50	0.95
EMC59010160	1.0	4	1.5	16	50	0.95
EMC59010200	1.0	4	1.5	20	55	0.95
EMC59012040	1.2	4	1.8	4	45	1.15
EMC59012060	1.2	4	1.8	6	45	1.15
EMC59012080	1.2	4	1.8	8	45	1.15
EMC59012100	1.2	4	1.8	10	45	1.15
EMC59012120	1.2	4	1.8	12	45	1.15
EMC59012160	1.2	4	1.8	16	50	1.15
EMC59014060	1.4	4	2.1	6	45	1.35
EMC59014080	1.4	4	2.1	8	45	1.35
EMC59014100	1.4	4	2.1	10	45	1.35
EMC59014120	1.4	4	2.1	12	45	1.35
EMC59014140	1.4	4	2.1	14	50	1.35
EMC59014160	1.4	4	2.1	16	50	1.35
EMC59014220	1.4	4	2.1	22	55	1.35
EMC59015060	1.5	4	2.3	6	45	1.45
EMC59015080	1.5	4	2.3	8	45	1.45
EMC59015100	1.5	4	2.3	10	45	1.45
EMC59015120	1.5	4	2.3	12	45	1.45
EMC59015140	1.5	4	2.3	14	50	1.45
EMC59015160	1.5	4	2.3	16	50	1.45
EMC59015180	1.5	4	2.3	18	55	1.45
EMC59015200	1.5	4	2.3	20	55	1.45
EMC59016060	1.6	4	2.4	6	45	1.55
EMC59016080	1.6	4	2.4	8	45	1.55
EMC59016100	1.6	4	2.4	10	45	1.55
EMC59016120	1.6	4	2.4	12	45	1.55
EMC59016140	1.6	4	2.4	14	50	1.55
EMC59016160	1.6	4	2.4	16	50	1.55
EMC59016180	1.6	4	2.4	18	55	1.55
EMC59016200	1.6	4	2.4	20	55	1.55
EMC59016260	1.6	4	2.4	26	60	1.55
EMC59018060	1.8	4	2.7	6	45	1.75
EMC59018080	1.8	4	2.7	8	45	1.75
EMC59018100	1.8	4	2.7	10	45	1.75
EMC59018120	1.8	4	2.7	12	45	1.75
EMC59018140	1.8	4	2.7	14	50	1.75
EMC59018160	1.8	4	2.7	16	50	1.75
EMC59018180	1.8	4	2.7	18	55	'1.75
EMC59018200	1.8	4	2.7	20	55	1.75
EMC59018260	1.8	4	2.7	26	65	1.75
EMC59020060	2.0	4	3	6	45	1.95
EMC59020080	2.0	4	3	8	45	1.95
EMC59020100	2.0	4	3	10	45	1.95
EMC59020120	2.0	4	3	12	45	1.95
EMC59020140	2.0	4	3	14	50	1.95
EMC59020160	2.0	4	3	16	50	'1.95
EMC59020180	2.0	4	3	18	55	1.95
EMC59020200	2.0	4	3	20	55	1.95
EMC59020220	2.0	4	3	22	60	1.95
EMC59020260	2.0	4	3	26	60	1.95
EMC59020300	2.0	4	3	30	70	1.95
EMC59025080	2.5	4	3.7	8	45	2.4
EMC59025100	2.5	4	3.7	10	45	2.4
EMC59025120	2.5	4	3.7	12	45	2.4
EMC59025140	2.5	4	3.7	14	50	2.4
EMC59025160	2.5	4	3.7	16	55	2.4
EMC59025180	2.5	4	3.7	18	55	2.4
EMC59025200	2.5	4	3.7	20	60	2.4
EMC59025260	2.5	4	3.7	26	70	2.4
EMC59025300	2.5	4	3.7	30	80	2.4
EMC59030080	3.0	6	4.5	8	45	2.85
EMC59030100	3.0	6	4.5	10	45	2.85
EMC59030120	3.0	6	4.5	12	50	2.85
EMC59030140	3.0	6	4.5	14	50	2.85
EMC59030160	3.0	6	4.5	16	55	2.85
EMC59030180	3.0	6	4.5	18	55	2.85
EMC59030200	3.0	6	4.5	20	60	2.85
EMC59030260	3.0	6	4.5	26	70	2.85
EMC59030300	3.0	6	4.5	30	70	2.85
EMC59030360	3.0	6	4.5	36	80	2.85
EMC59030400	3.0	6	4.5	40	90	2.85
EMC59040100	4.0	6	6	10	10	3.85
EMC59040120	4.0	6	6	12	12	3.85
EMC59040160	4.0	6	6	16	16	3.85
EMC59040200	4.0	6	6	20	20	3.85
EMC59040260	4.0	6	6	26	26	3.85
EMC59040300	4.0	6	6	30	30	3.85
EMC59040360	4.0	6	6	36	36	3.85
EMC59040400	4.0	6	6	40	40	3.85
EMC59040460	4.0	6	6	46	46	3.85
EMC59040500	4.0	6	6	50	50	3.85
EMC59050160	5.0	6	7.5	16	16	4.85
EMC59050200	5.0	6	7.5	20	20	4.85
EMC59050260	5.0	6	7.5	26	26	4.85
EMC59050300	5.0	6	7.5	30	30	4.85
EMC59050360	5.0	6	7.5	36	36	4.85
EMC59050400	5.0	6	7.5	40	40	4.85
EMC59050500	5.0	6	7.5	50	50	4.85
EMC59060200	6.0	6	9	20	20	5.85
EMC59060300	6.0	6	9	30	30	5.85
EMC59060400	6.0	6	9	40	40	5.85
EMC59060500	6.0	6	9	50	50	5.85
