Mũi taro hệ inch UNC YG1 T1272

Liên hệ

Mã sản phẩm: T1272
Thương hiệu: YG1
Công nghệ: Hàn Quốc
Xuất xứ: Hàn Quốc
Bảo hành: 06 tháng
Trọng lượng: 0.1 Kg

Title:

Kích thước:

Màu sắc:

Mũi taro hệ inch UNC, UNF YG1 T1272...series

Vật liệu: HSS-EX

SPIRAL POINT TAPS for GENERAL PURPOSE

- Suitable for tapping Through holes in Carbon Steels and Alloy Steels, where chips are produced in a continuous coil state.

SIZE	TPI	EDP No.	Thread	Overall	Shank	Square	Tapping	No. of
SIZE	TPI	EDP No.	Length	Length	Diameter	Size	Drill Dia	Flute
ØD1			L2	L1	ØD2	K	Ød1
#4	40 UNC	T1272162	8.5	44	3	2.5	2.3	2
#4	48 UNF	T1272182	8.5	44	3	2.5	2.4	2
#5	40 UNF	T1272202	11	46	4	3.2	2.6	3
#5	44 UNC	T1272222	11	46	4	3.2	2.7	3
#6	32 UNF	T1272242	13	48	4	3.2	2.8	3
#6	40 UNC	T1272262	13	48	4	3.2	2.9	3
#8	32 UNF	T1272282	13	52	5	4	3.4	3
#8	36 UNC	T1272302	13	52	5	4	3.5	3
#10	24 UNF	T1272322	16	60	5.5	4.5	3.9	3
#10	32 UNC	T1272342	16	60	5.5	4.5	4.1	3
3/16	32 UNF	T1272352	16	60	5.5	4.5	4	3
#12	24 UNC	T1272362	16	60	5.5	4.5	4.5	3
#12	28 UNF	T1272382	16	60	5.5	4.5	4.6	3
1/4	20 UNC	T1272402	19	62	6	4.5	5.1	3
1/4	28 UNF	T1272422	19	62	6	4.5	5.5	3
5/16	18 UNC	T1272442	22	68	6.1	5	6.6	3
5/16	24 UNF	T1272462	22	68	6.1	5	6.9	3
3/8	16 UNC	T1272482	24	75	7	5.5	8	3
3/8	24 UNF	T1272502	24	75	7	5.5	8.5	3
7/16	14 UNC	T1272522	25	80	8	6	9.4	3
7/16	20 UNF	T1272542	25	80	8	6	9.9	3
1/2	13 UNC	T1272562	29	85	9	7	10.8	3
1/2	20 UNF	T1272582	29	85	9	7	11.5	3
9/16	12 UNC	T1272602	30	90	10.5	8	12.2	3
9/16	18 UNF	T1272622	30	90	10.5	8	12.9	3
5/8	11 UNC	T1272642	32	95	12	9	13.6	3
5/8	18 UNF	T1272662	32	95	12	9	14.5	3
3/4	10 UNC	T1272702	37	105	14	11	16.5	3
3/4	16 UNF	T1272722	37	105	14	11	17.5	3
7/8	9 UNC	T1272742	38	115	17	13	19.5	3
7/8	14 UNF	T1272762	38	115	17	13	20.5	3
1"	8 UNC	T1272782	45	125	20	15	22.2	3
1"	12 UNF	T1272802	45	125	20	15	23.2	3
1"	14 UNC	T1272812	45	125	20	15	23.6	3
1-1/8"	7 UNF	T1272822	48	135	22	17	25	3
1-1/8"	12 UNC	T1272842	48	135	22	17	26.5	3
1-1/4"	7 UNF	T1272862	51	145	24	19	28.2	3
1-1/4"	12 UNC	T1272882	51	145	24	19	29.5	3
1-1/2"	6 UNF	T1272942	60	160	30	23	34	3
1-1/2"	12 UNC	T1272962	60	160	30	23	36	3
2"	4-1/2 UNF	T1272D22	70	195	40	32	45.2	3
2"	12 UNC	T1272D62	70	195	40	32	48.5	3

Mô tả

Mũi taro hệ inch UNC, UNF YG1 T1272...series

Vật liệu: HSS-EX

SPIRAL POINT TAPS for GENERAL PURPOSE

- Suitable for tapping Through holes in Carbon Steels and Alloy Steels, where chips are produced in a continuous coil state.

SIZE	TPI	EDP No.	Thread	Overall	Shank	Square	Tapping	No. of
SIZE	TPI	EDP No.	Length	Length	Diameter	Size	Drill Dia	Flute
ØD1			L2	L1	ØD2	K	Ød1
#4	40 UNC	T1272162	8.5	44	3	2.5	2.3	2
#4	48 UNF	T1272182	8.5	44	3	2.5	2.4	2
#5	40 UNF	T1272202	11	46	4	3.2	2.6	3
#5	44 UNC	T1272222	11	46	4	3.2	2.7	3
#6	32 UNF	T1272242	13	48	4	3.2	2.8	3
#6	40 UNC	T1272262	13	48	4	3.2	2.9	3
#8	32 UNF	T1272282	13	52	5	4	3.4	3
#8	36 UNC	T1272302	13	52	5	4	3.5	3
#10	24 UNF	T1272322	16	60	5.5	4.5	3.9	3
#10	32 UNC	T1272342	16	60	5.5	4.5	4.1	3
3/16	32 UNF	T1272352	16	60	5.5	4.5	4	3
#12	24 UNC	T1272362	16	60	5.5	4.5	4.5	3
#12	28 UNF	T1272382	16	60	5.5	4.5	4.6	3
1/4	20 UNC	T1272402	19	62	6	4.5	5.1	3
1/4	28 UNF	T1272422	19	62	6	4.5	5.5	3
5/16	18 UNC	T1272442	22	68	6.1	5	6.6	3
5/16	24 UNF	T1272462	22	68	6.1	5	6.9	3
3/8	16 UNC	T1272482	24	75	7	5.5	8	3
3/8	24 UNF	T1272502	24	75	7	5.5	8.5	3
7/16	14 UNC	T1272522	25	80	8	6	9.4	3
7/16	20 UNF	T1272542	25	80	8	6	9.9	3
1/2	13 UNC	T1272562	29	85	9	7	10.8	3
1/2	20 UNF	T1272582	29	85	9	7	11.5	3
9/16	12 UNC	T1272602	30	90	10.5	8	12.2	3
9/16	18 UNF	T1272622	30	90	10.5	8	12.9	3
5/8	11 UNC	T1272642	32	95	12	9	13.6	3
5/8	18 UNF	T1272662	32	95	12	9	14.5	3
3/4	10 UNC	T1272702	37	105	14	11	16.5	3
3/4	16 UNF	T1272722	37	105	14	11	17.5	3
7/8	9 UNC	T1272742	38	115	17	13	19.5	3
7/8	14 UNF	T1272762	38	115	17	13	20.5	3
1"	8 UNC	T1272782	45	125	20	15	22.2	3
1"	12 UNF	T1272802	45	125	20	15	23.2	3
1"	14 UNC	T1272812	45	125	20	15	23.6	3
1-1/8"	7 UNF	T1272822	48	135	22	17	25	3
1-1/8"	12 UNC	T1272842	48	135	22	17	26.5	3
1-1/4"	7 UNF	T1272862	51	145	24	19	28.2	3
1-1/4"	12 UNC	T1272882	51	145	24	19	29.5	3
1-1/2"	6 UNF	T1272942	60	160	30	23	34	3
1-1/2"	12 UNC	T1272962	60	160	30	23	36	3
2"	4-1/2 UNF	T1272D22	70	195	40	32	45.2	3
2"	12 UNC	T1272D62	70	195	40	32	48.5	3
